Mishimoto MMINT-ULSL Universal Intercooler L-Line, Silver

Part # MMINT-ULSLSKU MISMMINT-ULSL

Universal fit

Specifications
BrandMishimoto
Part typeIntercooler
Core ColorSilver
Core Height12.14 in
Core Length26.57 in
Core MaterialAluminum
Core Thickness3.93 in
Grade TypePerformance
Height12.89 in
Inlet Fitting GenderMale
Inlet Outside Diameter2.4 in
Inlet Tank MaterialAluminum
Install Difficulty3
Length40.22 in
OptionLabelSilver
Outlet Fitting GenderMale
Outlet Outside Diameter2.4 in
SellingPoint01Durable bar-and-plate core provides superior heat transfer and effectively reduce charge air temps
SellingPoint02Massive, 4"-thick core and 2.4" inlet/outlet support up to 1,000 horsepower
SellingPoint03Robust, one-piece cast aluminum end tanks withstand up to 60 PSI of boost pressure
SellingPoint04Three integrated mounting points with pre-threaded M6 holes make mounting easy
SellingPoint05Included bracket for harnesses or sensors keeps wiring safe and secure
SellingPoint06Precision TIG-welded joints won't crack under pressure
SellingPoint07Available in durable stealth black or sleek silver powder-coated finish
SellingPoint08Mishimoto Lifetime Warranty
TechSpec Core Height (in)12.14
TechSpec Core Length (in)26.57
TechSpec Core Thickness (in)3.93
TechSpec Core TypeBar-and-Plate
TechSpec Includes(1) Universal L-Line Intercooler-- Mishimoto Lifetime Warranty
TechSpec Inlet (in)2.4
TechSpec Maximum Recommended Boost Pressure (PSI)60
UPC / GTIN00840197720899
WarrantyLifetime Warranty
  • Durable bar-and-plate core provides superior heat transfer and effectively reduce charge air temps
  • Massive, 4"-thick core and 2.4" inlet/outlet support up to 1,000 horsepower
  • Robust, one-piece cast aluminum end tanks withstand up to 60 PSI of boost pressure

Description

Big power requires big cooling, and Mishimoto is here to deliver. This Mishimoto universal L-line intercooler features a massive 4"-thick core that's capable of supporting up to 1,000 horsepower. The one-piece, cast-aluminum end tanks are far stronger than cut-and-weld tanks, making them capable of holding up to 60 PSI of boost. Large 2.4" inlet and outlets ensure ample flow, while the 26.57"x12.4" bar-and-plate core effectively transfers heat out of your charge air. Unlike many stock plastic end tank intercoolers, our end tanks are precision TIG-welded to the core for durability and reliability, pass after pass.----This universal L-line intercooler features three integrated mounts with pre-threaded M6 holes to make fabricating mounts and installing easy. The center support mount also ensure the intercooler is properly supported for aggressive driving. An integrated harness/sensor mount makes keeping your wires safe and tidy easy. This intercooler is available in a durable sleek silver or stealth black powder-coated finish. Like all our performance products, this universal L-line bar-and-plate intercooler is backed by our Mishimoto Lifetime Warranty.
