FAST Race Supercharger Kit for GM LS3

Part # 303012SKU FAS303012

Universal fit

Specifications
BrandFAST
Part typeSupercharger Kit
Advertised Exhaust Duration302 deg
Advertised Intake Duration291 deg
Application2007-2014 GM LS3 Rectangle Port
Assembly Lubricant IncludedNo
Basic Operating RPM Range2,300-7,400 RPM
Cam TypeHydraulic Roller
Camshaft Gear Attachment3-Bolt
Camshaft MaterialBillet Steel
Engine FamilyGM LS GEN III/IV 3-Bolt 8 Cylinder (1997-2015)
Exhaust Duration at .050 inch Lift247 deg
Exhaust Valve Lift0.614 in
Exhaust Valve Lift with Factory Rocker Arm Ratio0.614 in
FinishBlack Powder Coated
Grind Number281MGH15
Includes Air to Water Water Pump?No
Includes Coil Covers?No
Includes Fuel Injectors?No
Includes Heat Exchanger Coolant Hoses?No
Includes Heat Exchanger Mounting Hardware?No
Includes Heat Exchanger Reservoir?No
Includes Heat Exchanger?No
Includes Intercooler Core?No
Includes MAP Sensor?Yes
Includes Tune?No
Intake Duration at .050 Inch Lift233 deg
Intake Seals Included?Yes
Intake Valve Lift0.612 in
Intake Valve Lift with Factory Rocker Arm Ratio0.612 in
Lifter TypeHydraulic Roller
Lobe Separation115 deg
UPC / GTIN00036584413653

Description

FAST Rectangular Port Supercharger/Camshaft Power Packages for GM LS3

FAST Rectangular Port Supercharger/Camshaft Power Packages for GM LS3 provide the perfect paring of products for enthusiasts looking for 850+ hp potential from their GM LS3 engine. They feature Edelbrock's 2300 TVS supercharger with integrated intercooler and COMP Cams' LST camshaft designed for supercharger applications. These FAST Power Packages for GM LS3 have all the basics required to install the supercharger, but necessary accessories such as fuel injectors, air intake, and heat exchanger pump are left up to the installer, providing total flexibility for custom installations.< br></br>

FAST Edelbrock/COMP Cams Power Packages for GM LS include:

< ul>< li>2300 TVS supercharger integrated high-capacity, dual bar and plate intercooler enables major power gains through lower inlet air charge temperatures</li>< li> Supercharger pulleys:</li>< li> -- 3.500 in. is pump gas-friendly supercharger pulley for engine break-in, initial tuning, and general performance driving</li>< li> -- 2. 750 in. when maximum power is desired on race fuel or E85</li>< li> Accessory drive pulleys</li>< li> Fuel lines and rails</li>< li> Low Shock Technology camshaft</li>< li> Phaser limiter</li>< li> Pushrods</li>< li> Conical valve springs</li>< li> Chromoly steel retainers</li>< li> Valve locks and seals</li>< li> Spring seats and shims</li>< li> Installation hardware</li></ul>
